Western Building Supply
All Buildings
The Lander 32x48 pole barn — image 1 of 31 / 3

Shops & Garages

The Lander

32×48×12 · 1,536 sq ft

Mid-size shop with covered porch — built for the way you actually use the space.

Dimensions

32′ × 48′ × 12

Square Feet

1,536

Doors

(2) 10'x10' insulated sandwich-style overhead doors · (3) 3068 walk doors, (1) 6068 double door

Windows

(3) 3'x3' Windows

Built for More Than Just Parking

The Lander is a 32×48 shop with a 16-foot covered porch — 1,536 square feet of enclosed workspace plus protected outdoor space for the stuff that doesn't need to be inside but shouldn't be sitting in the weather. Two 10×10 overhead doors on the front give you drive-through access for trucks, trailers, and equipment. Three walk doors and a 6-foot double door mean you're never walking the long way around. The covered porch runs the full length of one side — perfect for a workbench setup, material staging, or just getting out of the sun with a cold drink at the end of the day. This package ships with ZIP System sheathing on the roof and walls — meaning it's insulation-ready from day one. Two-tone steel (Ash Gray walls, Charcoal roof and trim) gives it a clean, finished look that fits on a residential property or a commercial lot. The Lander is named after the Wyoming town at the base of the Wind River Range — a place where people work hard, play harder, and expect their buildings to keep up.

Specifications

Width32 ft
Length48 ft
Eave Height12 ft
Square Footage1,536 sq ft
Roof Pitch4/12
Overhangs16" all sides
Post Spacing8' on center
Truss Spacing4' on center, Western-manufactured
Columns3-ply laminated, treated, 60-year warranty
Overhead Doors(2) 10'x10' insulated sandwich-style overhead doors
Walk Doors(3) 3068 walk doors, (1) 6068 double door
Windows(3) 3'x3' Windows
Porch16' covered porch, full length of one side, exposed columns

What’s In the Package

  • Stamped engineering
  • Custom-manufactured trusses (4/12 pitch, 20" heel, 4' on center)
  • 2x6 3-ply laminated columns with Sturdi-Wall Plus brackets
  • LVL beams for porch structure
  • 26ga TM Classic steel — Ash Gray Textured walls, Charcoal Textured roof
  • All trim, fascia, soffit (vented), rat guard, ridge cap
  • (2) 10'x10' insulated overhead doors (sandwich style, white)
  • (3) 3068 walk doors with lock sets
  • (1) 6068 double door with lock set
  • ZIP System sheathing (5/8" roof, 7/16" walls) with tape and roller
  • Framing lumber and pressure-treated lumber
  • Vented closures and outside closures
  • All fasteners and hardware
  • Jobsite package (saw blades, bit holders, caulk, paint pens)
  • Builder appreciation box
  • Delivery on Western trucks

What’s Not Included

Concrete / foundation Insulation Interior framing and finish Electrical and plumbing Permits (we help with the process)

Need a contractor? Find one in our Contractor Network.

Make It Yours

Wainscot in a contrasting color or wood-print steel Diamond Kote siding on the porch section Windows (3040 or 4040 sliders) Cupola for ventilation and curb appeal Overhead door upgrades (insulated, windload-rated, or larger sizes) Additional walk doors or windows Lean-to extensions

Foundation & Site Prep

The Lander uses Sturdi-Wall Plus wet-set brackets — your concrete contractor sets the brackets in the slab before the building crew arrives. We provide a foundation plan with exact bracket placement dimensions as part of the engineering package. Most contractors pour a 4" slab with thickened edges at column locations.

Permits & Engineering

Most counties require a building permit for a structure this size. Your Western engineering package includes stamped plans that satisfy most jurisdictions. We recommend pulling your permit before pouring concrete — your local building department will tell you exactly what they need, and our engineering team can help answer their questions.

The Build Process

Once your foundation is poured and brackets are set, your crew can start framing. Western delivers the full package on our trucks — trusses, steel, columns, doors, hardware, and fasteners all arrive together. An experienced post-frame crew typically frames and closes in a 32×48 in 5–7 working days. Interior finish timeline depends on your scope.

How Much Does a 32x48 Pole Barn Cost?

A 32×48 post-frame building package from Western typically falls in the $35,000–$50,000 range depending on configuration, door selections, and upgrades. This is a materials package price — it does not include concrete, labor, insulation, or interior finish. The Lander ships as a complete, ready-to-build package with everything your crew needs above the foundation.

Frequently Asked Questions

Your engineering package includes a foundation plan with exact dimensions. Typical slab is 32×48 with a porch extension, 4 inches thick with thickened edges at column locations. Your concrete contractor will use the bracket layout we provide.

Get a Price on The Lander

Request a quote and a Western team member will call you back with a real number — usually the same business day.

Call NowGet a Price
